| Product Specification |
| Display |
- 18.5inch CCFL Panel with High intensity transparent front glass. |
| CPU |
Intel Atom N330(1M Cache, 1.6 Ghz, Dual Core) TDP SW support
Intel Montevina or calpella platform |
| Chipset |
Intel 945GSE + ICH7-M |
| Memory |
1G DDR2 |
| HDD |
160G (2.5inch SATA) |
| ODD |
DVD Combo<- Option |
| Sound |
2Channel output, three audio jack |
| I/O Port |
4x USB 2.0 ports (TBD), 1x SPDIF jack,1x DC-In jack
1x Headphone jack, 1x Microphone jack, 1x Internal Microphone
1x RJ45 port for LAN, 1x 4in1 Card reader
1x TV Turner <- Option
the TV Tuner supports global analog standards
Including NTSC, PAL and SECAM
Digital Standards (DTV-T, ISDB-T, TDMB, ISDB-T,ATSC) |
| Slots |
2x Mini PCI-E slots : one for WIFI % bluetooth module or WIFI only ;
one for TV card, 2x DIMM slot |
| LAN |
On board 10/ 100MB/ 1000MB LAN, Wifi + Bluetooth combo module |
| Remote control |
IR MCE remoter(1,Support MCE standard Control the TV turner) |
| PC Camera |
1.3 Mega Pixels |
| Battery |
Polymer battery |
| Thermal |
Cooling thermal system with smart fan |
| OS |
Dos |
| Adapter |
65W |
|
18.5"
