| Model |
KM2055 |
KM2043 |
KM2041 |
| Display |
20inch Wide 16:9 HD (1600 x 900 ) Resolution |
| Socket |
ILGA1156 |
LGA775 / Up to 1333 MHz Front Side Bus |
| Processor Support |
Inteld® Core i3 |
Intel Core 2 Quad |
| Inteld® Core i5 |
Intel Core 2 Duo |
Inteld® Core Processors
with Intel HD Graphics |
Intel Pentium / Celeron |
| Memory Supportr |
DDR3-1066/1333 |
DDR2-800 |
DDR3-1066 |
2 x 240 pin DDR3 DIMM
Slots |
2 x 240 pin DDR2 DIMM
Slots |
2 x 240 pin DDR3 DIMM
Slots |
| Up to 8GB Ram |
Up to 8GB Ram |
Up to 4GB Ram |
| Features |
Intel HD Graphics ready |
Intel Graphis Media Accelerator X4500 |
Intel Clear Video HD
technology |
Microsoft DirectX 10 |
| Microsoft DirectX 10 |
Shader Model 4.0 |
| Shader Model 4.0 |
OpenGL 2.0 |
Microsoft Windows7/Vista
Premium ready |
Microsoft Windows7/Vista Premium ready |
| OpenGL 2.1 |
High-Definition Audio |
| I/O Port |
13 USB Ports |
9 USB Ports |
1 HD Audio Port
[7.1-Channel] |
1 Serial Port Header |
| 1PS/2 Keyboard Port |
1 HD Audio Port |
1 Digital Optical S/PDIF
outputs |
1 PS/2 Keyboard Port |
1 Ethernet
[10/100/1000Mbps] |
1 Ethernet[10/100/1000Mbps] |
| 2 Audio Header |
2 Headphone, 2 Microphone |
| DVI / VGA |
1 x 5 in 1 Card Reader / CF 1/2 Card Reader |
| 2 WiFi Antennas |
DVI |
| 2Headphone, 2Microphone |
1 WiFi Antenna |
1 x 5 in 1 Card Reader /
CF 1/2 Card Reader |
|
| Slots |
1 x PCI Express x16 |
| PC Camera |
1.3Mega Pixels & HD Camera |
| Speaker |
Integrated 2 x 3W(MAX) |
| Microphone |
Integrated Mic |
| Option |
HDD |
250G(Up to 1TB,2.5inch SATA) |
| ODD |
Super Multi DVD-Slim or Tray Type |
| Memory |
(Up to 8G) |
| Touch |
P-Cap,SAW,IR Multi Touch(Win7) |
| RS232 |
4 Ports |
| WiFi |
802.11n WiFi |
| PCI Riser Card |
x1,x16 Riser Board |
| Security |
Finger Print System |
| RF Card Systems |
| Smart Card Syatems |
| HDD+ |
Mobile Rack (Slot) |
| Auto Cooling System |
Cooling + Temp Sens |
| Color |
Black, White,OEM Color |
| A/C Adapter |
110~220V, 180W |
20"
