 20" + 2in1
|
| |
 |
| |
best new all in one computers |
 |
- All in One PC with the network switch contains 2 separate inbuilt PCs with a optical device in one cabinet
(1 display, 1 keyboard, 1 mouse) what means the comfort, more working space and less expenses.
- Both inbuilt PCs have its own OS and can work simultaneously, Network switch provides an easy switching between 2 simultaneously working PC OSs and correspondingly between an internal network and an external network without reloading.
- The inbuilt PC for the internal network can be protected by a Biological system(finger print) or/and
a RF reader options.
|
|
 |
- All functions of Standard AIO PC and AIO PC with RFID or biological system
- Developed in accordance with the Russian national police agency with anti-hacking as priority.
- Allows inside and outside network booting at the same time by turning on the power.
- Just the touch of a switch on the PC switches from the inside network to the Internet.
- Hackers need to press keys directly on the PC screen in order to access!
|
|
|
| |
| Specification #1 |
| Display features |
20" wide TFT LCD 1600*900, 16:9 HD |
| Input |
PS/2 keyboard and mouse |
| Access system |
RF card reader |
| Speaker |
Integrated 2x3W(max) |
| Touch screen |
Infrared type |
| Platforms |
Public module |
Public module |
| CPU |
socket LGA775 Intel® Core 2™ Quad,
Intel® Core 2™ Duo, Intel® Pentium®,
Intel® Celeron®, Support CPU up to 65W TDP
|
Socket LGA1155 2nd Generation
Intel® Core™ series2000 Series
Intel® Core™ i3, i5 & i7
|
| Chipset |
Intel® G43 Express GMCH |
Intel® H67 Express |
| Graphics Card |
on board, based on GMA X4500 |
on board, Intel® HD Graphics 2000/3000 ready |
| Memory |
2 x DDRII-800, Up to 8GB |
DDRIII-1066/1333, Up to 16GB |
| Storage |
1 x 2.5" SATA HDD |
1 x 2.5" SATA HDD |
| ODD |
Samsung DVD+/-RW Dual Layer Slimline TS-L633 |
Samsung DVD+/-RW Dual Layer Slimline TS-L633 |
| WebCam |
Built-in USB CAMERA 1.3 m for high video quality |
Built-in USB CAMERA 1.3 m for high video quality |
| Expansion slots |
1 x PCI Express x16
1 x mini PCI Express
(occupied by WiFi module)
|
1 x PCI Express x16
1 x mini PCI Express
(occupied by WiFi module)
|
| Wireless LAN |
802.11n/g/b |
802.11n/g/b, 2 x WiFi antennas |
| LAN |
10/100/1000 Mbps Ethernet LAN |
10/100/1000 Mbps Ethernet LANs |
| External Ports |
9 x USB 2.0 |
9 x USB 2.0, 1 x USB 3.0 |
1 x 5 in 1 Card Reader
CF 1/2 Card Reader
|
1 x 5 in 1 Card Reader
CF 1/2 Card Reader
|
| 1 x eSATA |
1 x eSATA |
| Analog 6-ch HD |
Analog 6-ch HD,
1 Digital Optical S/PDIF output
|
DC input |
19V / 7,89A |
19V / 7,89A |
|
|
| |
| Specification #2 |
| Display features |
20" wide TFT LCD 1600*900, 16:9 HD |
| Input |
PS/2 keyboard and mouse |
| Access system |
RF card reader |
| Speaker |
Integrated 2x3W(max) |
| Touch screen |
Infrared type |
| Platforms |
Secure module |
Secure module |
| CPU |
Intel® Core™ i7/ i5/ i3
Mobile processor in the rPGA988A socket ( Dual-Core )
|
Intel® Core™ i7/ i5/ i3
Mobile processor in the rPGA988A socket ( Dual-Core )
|
| Chipset |
Intel QM57 |
Intel QM57 |
| Graphics Card |
on board, based on Intel QM57 chipset |
on board, based on Intel QM57 chipset |
| Memory |
1 x DDRIII SO-DIMM 800/1066 MHz up to 4GB |
1 x DDRIII SO-DIMM 800/1066 MHz up to 4GB |
| Storage |
1 x 2.5" SATA HDD |
1 x 2.5" SATA HDD |
| ODD |
Not present |
Not present |
| WebCam |
Not present |
Not present |
| Expansion slots |
1 x Mini PCIE socket,
1 x Mini PCI socket to support Mini PCI Type IIIA
|
1 x Mini PCIE socket,
1 x Mini PCI socket to support
Mini PCI Type IIIA |
| Wireless LAN |
Not present |
Not present |
| LAN |
1 x Intel 82574L Gigabit LAN |
1 x Intel 82574L Gigabit LAN |
| External Ports |
Not present |
Not present |
| Not present |
Not present |
| Not present |
Not present |
| Not present |
Not present |
DC input |
9~24V/ 60W |
9~24V/ 60W |
|
|
|
|
|
